Bolt-down gate stopper designed to limit the opening travel of swing and sliding gates, with a rubber contact face and silver zinc plated steel frame.
Swing and Sliding Gate Use: Provides a fixed stopping point to prevent the gate from opening too far.
Rubber Contact Face: Provides a rubber buffer between the gate and the steel frame.
Bolt-Down Mounting: Allows secure fixing at the required gate stopping position.
Steel Frame Construction: Supports the rubber stopper at the gate’s stopping point.
Corrosion Resistant Finish: Silver zinc plating helps protect the steel frame from rust.
90mm Stopper Centre Height: Positions the rubber stopper centre 90mm above the base for alignment with the gate.
Description
The Richmond GTR018 is a bolt-down gate stopper for swing and sliding gates. It provides a physical stopping point to prevent the gate from opening too far, with a rubber contact face supported by a silver zinc plated steel frame.
The bolt-down base lets the stopper be positioned where the gate needs to stop. Check that the gate will meet the rubber face at that position, rather than the frame or mounting base.
The centre of the rubber stopper is 90mm above the base, while the overall height is 110mm. Use the centre height to check where the gate will contact the stopper and the overall height when allowing for clearance. Compare the base dimensions and fixing layout in the specification drawing with the available mounting area.
Gate application
Swing and sliding gates
Mounting Type
Bolt-down base
Frame Material
Steel
Frame finish
Silver zinc plated
Stopper material
Rubber
Rubber stopper centre height
90mm
Overall Height (H)
110mm
Upright span (A)
70mm
Base length (B)
130mm
Base width (C)
100mm
