250mm Swivel Extra Hp Castor (S1063B)

Castor Frame Type: Swivel with Brake

Wheel Diameter: 250mm

Castor Height: 370mm

Swivel Radius: 210mm

Wheel Bearing Type: Taper Roller Bearing

Maximum Load Capacity: 2000kg

Wheel Type: Polyurethane

Wheel Code: PU1061 x 2

In a class of its own, the EHP series outperforms all rivals no matter how tough the circumstances. Developed using Richmond’s 50 plus years of castor know how, features include a large opposed taper roller bearing swivel head and precision robot welded fully sealed construction to give a long life without costly breakdowns. The EHP series are fully towable at speeds up to 16kph on flat surfaces without obstacles, making them ideal for work in heavy duty applications. The castor’s twin wheel design not only increases surface contact but controls the rolling speed of each wheel when turning and manoeuvering. Custom designed and manufactured in-house, we challenge you to find a better castor.

The S1063B manufactured by Richmond is a swivel frame castor and is fitted with 2 polyurethane tyred cast iron wheels. This swivel castor is in our extra high performance series range and can safely take loads up to 2000kg. The S1063B is assembled with taper roller bearings on the castors axle. The swivel frame design of this castor allows the castor to swivel 360°. The outside diameter of the polyurethane tyred cast iron wheels is 250mm, the wheels width is 2 x 50mm and can be ordered separately (PU1061).

SKU: 086EHPS1063B Categories: ,
