150mm Swing Type Jockey Wheel (S6066)

$92.40 ex. GST
$101.64 inc. GST

Available Online

Add to Quote
For bulk enquiries contact your nearest Richmond store or add to quote to get the best freight rate!

The S6066 is a swing type jockey wheel, ideal for use on caravans, campers, boat trailers and other trailers used for transporting goods for leisure or business.

The S6066 features a new heavy duty plate assembly, designed to swing up and out of the way. See example of heavy duty plate assembly below. Important Note: When moving equipment, best performance is achieved with jockey wheel being at a lowest position. Moving equipment with jockey wheel in a high position is not safe or advised. All load capacities are based on smooth concrete or asphalt surfaces.

Description

Featuring a new heavy duty plate assembly, this Jockey Wheel is designed to swing up and out of the way when not in use. Ideal for your caravan, boat trailer or any other trailer!

One of the most popular Jockey Wheels in our collection, this clever Swing Type Jockey Wheel is simple to use and incredibly tough. It includes a static load capacity of 350kg (based on smooth concrete or asphalt surfaces) and is an essential piece of equipment for owners of caravans or trailers.

Why you’ll love this Swing Jockey Wheel

  • Easy-to-use design for both trailers and caravans
  • 360 degree rotation provides outstanding manoeuvrability
  • Allows for simple, quick alignment with your vehicle
  • Superior strength and reliability compared to other jockey wheels
  • Precision manufactured by a team of in-house engineers

When moving your trailer or caravan, best performance is achieved when your jockey wheel is at its lowest position. Moving equipment with the jockey wheel in a high position is not safe or advised.

How does a swing style Jockey Wheel work?

To help you understand the design and function of a swing jockey wheel for your needs, we’ve outlined its main components below. These include:

Frame: The frame is the main structure that holds the wheel and allows it to pivot. It’s usually made of metal, such as steel or aluminium, to provide strength and support.

Mounting bracket: This attaches the jockey wheel to the trailer or caravan. It may be bolted or welded onto the front of the trailer, and it typically includes a mechanism for raising and lowering the jockey wheel.

Swivel mechanism: This allows the jockey wheel to pivot 360 degrees, providing manoeuvrability in any direction. It typically consists of a ball joint or other type of bearing that allows the wheel to rotate freely.

Wheel: Made from rubber, this is the part of the jockey wheel that comes into contact with the ground to provide support and manoeuvrability.

Handle: Used to raise and lower the jockey wheel. It’s typically located near the mounting bracket and may be designed to fold down or otherwise be out of the way when not in use.

Overall, the design of a swing jockey wheel is intended to provide support, manoeuvrability, and ease of use when hitching and unhitching your trailer or caravan.



Why choose Richmond Wheel & Castor Co for your Jockey Wheels?

Our growing range of high quality jockey wheels are ideal for use on trailers, caravans, campers, boat trailers, and various other trailers.

We offer two different mounting types – clamp and swing up – and three different wheel sizes, giving you the freedom to choose the best jockey wheel for your needs.

With load capacities of up to 400kgs, Richmond’s jockey wheels are a high-quality and economical solution to support and transport your trailer or caravan.

We’re proud to have over 60 years’ experience designing and manufacturing wheels of all kinds, helping to give our customers the very best in materials handling solutions.

If you can’t find the right jockey wheel for your needs, please get in touch with our friendly team to talk about your needs!



Richmond’s new range of jockey wheels are ideal for use on trailers, caravans, campers, boat trailers, and various other trailers. We offer two different mounting types – clamp and swing up – and three different wheel sizes. With load capacities of up to 400kgs, Richmond’s jockey wheels are a high-quality and economical solution. When it comes to wheels, we have over decades years of experience, and our jockey wheels are everything you’ve come to expect from Richmond. They’re strong, high-quality, and reliable. Jockey wheels can be used to lower your trailer or caravan onto a tow ball, or to move your trailer around by hand in small or tight spaces. Our swing up jockey wheels feature a brand new heavy duty plate assembly for even better performance. The swing up mechanism allows for your jockey wheel to swing up and out of the way when not in use, and is our most popular choice. Our jockey wheels can be raised and lowered to a variety of different heights to suit every application. Don’t compromise on quality – choose jockey wheels from Richmond. Have a question, or would like to buy our jockey wheels? Call our staff on 1300 474 246, email [email protected], or visit one of our showrooms in Melbourne, Sydney (we have branches in West Sydney and South Sydney), Brisbane, Perth, Adelaide or Darwin.

Product Code S6066
Wheel Diameter (mm) 150
Frame Style Swing
Wheel Width (mm) 45
Wheel Type Rubber
Wheel Code JKW006
Static Load Capacity (kg) 350 (when at lowest setting on a flat/level surface)
Raised Height (mm) 850
Lowered Height (mm) 540

Shipping Information

Flat rate shipping for all metropolitan and major regional locations where a Richmond Wheel & Castor warehouse is located.

Shipping will be calculated at checkout.

For more information on our freight charges, click & collect locations, and more
view our online shipping policy
