The S547B manufactured by Richmond Rolling Solutions is a swivel frame castor and is fitted with a polyurethane wheel. This swivel castor is part of our heavy duty welded series range and can safely take loads up to 330kg. The S547B wheel is fitted with ball bearings. This castors swivel frame allows the castor to swivel 360°. The outside diameter of the polyurethane wheel is 125mm, the wheel width is 35mm and can be ordered separately (PU549).
125mm Poli Ci Wheel 330Kg Capacity Castor (S547B)
International Shipping Available
The S547B manufactured by Richmond Rolling Solutions is a swivel frame castor and is fitted with a polyurethane wheel. This swivel castor is part of our heavy duty welded series range and can safely take loads up to 330kg. The S547B wheel is fitted with ball bearings. This castors swivel frame allows the castor to swivel 360°. The outside diameter of the polyurethane wheel is 125mm, the wheel width is 35mm and can be ordered separately (PU549).
Description
Precision built for durability under extreme working conditions, the Heavy Duty Welded Series is ideal for the exhaustive demands of industrial environments when a low profile high load bearing castor is required. Featuring a precision machined swivel ball race provides an unrivalled ultra smooth swivel action and a king pin made of high tensile steel to withstand high side impact loads. Finished in an attractive zinc plating to provide corrosion resistance, Richmond can also supply the heavy duty welded series in stainless steel for sue in high corrosive environments.
| Product Code | S547B |
|---|---|
| Wheel Diameter (mm) | 125 |
| Frame Type | Swivel with Brake |
| Wheel Width (mm) | 35 |
| Wheel Type | Polyurethane Tyred Cast Iron Centred |
| Wheel Code | PU549 |
| Wheel Bearing Type | Ball Bearing |
| Castor Height (mm) | 159 |
| Swivel Radius (mm) | 102 |
| Maximum Load Capacity (kg) | 330 |
| Recommended Load Capacity (kg) | 250 |
| Barcode / GTIN |
| Download CAD Drawing (STEP file) | Download |
|---|
