The S470 manufactured by Richmond Rolling Solutions is a swivel frame castor and is fitted with a cast iron wheel. This swivel castor is part of our heavy duty welded series range and has a maximum capacity of 400kg. The S470 is assembled with ball bearings on the castors axle. The swivel frame of this castor allows for full 360° swivel rotation. The overall cast iron wheel diameter is 100mm, the wheel width is 38mm and can be ordered separately (Ci400).
100mm Cast Iron Wheel 400Kg Capacity Castor (S470)
International Shipping Available
The S470 manufactured by Richmond Rolling Solutions is a swivel frame castor and is fitted with a cast iron wheel. This swivel castor is part of our heavy duty welded series range and has a maximum capacity of 400kg. The S470 is assembled with ball bearings on the castors axle. The swivel frame of this castor allows for full 360° swivel rotation. The overall cast iron wheel diameter is 100mm, the wheel width is 38mm and can be ordered separately (Ci400).
Description
Precision built for durability under extreme working conditions, the Heavy Duty Welded Series is ideal for the exhaustive demands of industrial environments when a low profile high load bearing castor is required. Featuring a precision machined swivel ball race provides an unrivalled ultra smooth swivel action and a king pin made of high tensile steel to withstand high side impact loads. Finished in an attractive zinc plating to provide corrosion resistance, Richmond can also supply the heavy duty welded series in stainless steel for sue in high corrosive environments.
| Product Code | S470Ci |
|---|---|
| Wheel Diameter (mm) | 100 |
| Frame Type | Swivel |
| Wheel Width (mm) | 38 |
| Wheel Type | Cast Iron |
| Wheel Code | Ci400 |
| Wheel Bearing Type | Ball Bearing |
| Castor Height (mm) | 132 |
| Swivel Radius (mm) | 90 |
| Maximum Load Capacity (kg) | 400 |
| Recommended Load Capacity (kg) | 300 |
| Barcode / GTIN |
| Download CAD Drawing (STEP file) | Download |
|---|
