The R10903 by Richmond is a rigid frame castor and uses a semi pneumatic wheel. This rigid castor is part of our 3000 series range and has a top load capacity of 3000kg. The R10903 uses ball bearings for wheel rotation. This castors rigid frame only allows linear movement unless used with swivel castors. The overall semi pneumatic wheel diameter is 250mm, the wheel width is 76mm and can be ordered separately (SG1040).
This extra heavy duty range has been precisely engineered and custom built to excel under the hardest conditions. Richmond’s 3000 Series picks up applications that our 1000 Series can not. An increased towing capacity and towing speed, increases the possibility for rolling solutions for the most abstract of trolleys and platforms.
| Product Code | R10903 |
|---|---|
| Wheel Diameter (mm) | 250 |
| Frame Type | Rigid |
| Wheel Width (mm) | 75 |
| Wheel Type | Spheroidal Graphite Iron |
| Wheel Code | SG1028 |
| Wheel Bearing Type | Ball Bearing |
| Castor Height (mm) | 310 |
| Swivel Radius (mm) | 190 |
| Maximum Load Capacity (kg) | 2500 |
| Towable | No |
| Download CAD Drawing (STEP file) | Download |
|---|
