125mm Swivel Chrome Durolite Castor (S5574D)

Wheel Diameter: 125mm

Castor Frame Type: Swivel with Directional Lock

Wheel Width: 32mm

Wheel Type: Institutional Rubber

Wheel Code: iR5008

Wheel Bearing Type: Ball Bearing

Castor Height: 161mm

Swivel Radius: 106mm

Maximum Load Capacity: 100kg

Recommended Load Capacity: 80kg

Truly the best looking durable castor in it’s class Richmond’s Chrome Durolite Series is Ideal for use in hospitals, institutions, nursing homes and an attractive edition to furniture and retail displays. The combination of a pressed metal frame and chrome finish provides both strength and corrosion resistance. A robust twin swivel race design provides durability and longevity in the workplace.

The S5574D manufactured by Richmond is a swivel frame castor and is fitted with a institutional rubber wheel. This swivel castor is in our chrome durolite plate range and can safely take loads up to 100kg. The S5574D uses ball bearings for wheel rotation and is plate mount. The swivel frame design of this castor permits the load to be steered. The institutional rubber wheel diameter is 125mm, the wheel width is 32mm and you can order separately (Part Number: iR5008). To order this castor without the direction lock, search for S5574.

This castor includes a directional lock  – This feature locks the swivel direction of the castor but still allows the wheel to turn. When the directional lock is released, full swivel function is returned to the castor. Castors with a directional lock are indicated by a ‘D’ at the end of the castor code, and feature a green pedal on the castor frame.
