400mm Twin Wheel Swivel 10 Tonne Load Castor (S1652D)

Add to Quote
For bulk enquiries contact your nearest Richmond store or add to quote to get the best freight rate!

The S1652D from Richmond Wheel and Castor Co. is a swivel frame castor and uses a polyurethane tyred cast iron wheel. This swivel castor is part of our extra high performance series range and can hold loads up to 10,000kg. The S1652D uses taper roller bearings for wheel rotation. This castors swivel frame allows the castor to swivel 360°. The diameter of the polyurethane tyred cast iron wheel is 400mm and can be ordered separately (PU1606).

This castor includes a directional lock  – This feature locks the swivel direction of the castor but still allows the wheel to turn. When the directional lock is released, full swivel function is returned to the castor. Castors with a directional lock are indicated by a ‘D’ at the end of the castor code.

Description

In a class of its own, the EHP series outperforms all rivals no matter how tough the circumstances. Developed using Richmond’s 6 decades of castor know how, features include a large opposed taper roller bearing swivel head and precision robot welded fully sealed construction to give a long life without costly breakdowns. The EHP series are fully towable at speeds up to 16kph on flat surfaces without obstacles, making them ideal for work in heavy duty applications. The castor’s twin wheel design not only increases surface contact but controls the rolling speed of each wheel when turning and manoeuvering. Custom designed and manufactured in-house, we challenge you to find a better castor.

Product Code S1652D)
Wheel Diameter (mm) 400
Frame Type Swivel with Directional Lock
Wheel Type Twin Polyurethane Tyred Cast Iron Centred
Wheel Code PU1606
Wheel Bearing Type Taper Roller Bearing
Castor Height (mm) 610
Swivel Radius (mm) 318
Maximum Load Capacity (kg) 10000
Australian Manufactured

Australian Manufactured

Swivel with Directional Lock

Swivel with Directional Lock

Towable

Towable
