The S10902D from Richmond is a swivel frame castor and uses a semi pneumatic wheel. This swivel castor is in our 3000 series range and has a maximum capacity of 2500kg. The S10902D is assembled with ball bearings on the castors axle. The swivel frame allows the castor to swivel 360°. The semi pneumatic wheel diameter is 250mm, the wheel width is 76mm and you can order separately (Part Number: SG1040). For the same castor without a direction lock, see S10902.
This castor includes a directional lock – This feature locks the swivel direction of the castor but still allows the wheel to turn. When the directional lock is released, full swivel function is returned to the castor. Castors with a directional lock are indicated by a ‘D’ at the end of the castor code.
This extra heavy duty range has been precisely engineered and custom built to excel under the hardest conditions. Richmond’s 3000 Series picks up applications that our 1000 Series can not. An increased towing capacity and towing speed, increases the possibility for rolling solutions for the most abstract of trolleys and platforms.
| Product Code | S10902D |
|---|---|
| Wheel Diameter (mm) | 250 |
| Frame Type | Swivel with Directional Lock |
| Wheel Width (mm) | 75 |
| Wheel Type | Spheroidal Graphite Iron |
| Wheel Code | SG1028 |
| Wheel Bearing Type | Ball Bearing |
| Castor Height (mm) | 310 |
| Swivel Radius (mm) | 190 |
| Maximum Load Capacity (kg) | 2500 |
| Towable | No |
