The S4034B from Richmond is a swivel frame castor and features a nylon wheel. This swivel castor is one of our 300 series plate range and can hold loads up to 200kg. The S4034B uses ball bearings for wheel rotation and is plate mount. The swivel frame allows the load to be steered. The outside diameter of the nylon wheel is 100mm, the wheel width is 35mm and you can order separately (Part Number: NY413). For the same castor without a brake, see S4034.
Meeting and exceeding all performance standards due to a higher load bearing capacity, the 300 Series has a wide range of uses. A nylon wheel in a 300 series is most common for industrial and trolley applications, a rebound rubber wheel is ideal for road cases and transportable crates whilst a poly nylon wheel is best suited to undercover and showroom displays. Cast Iron, Poly Cast Iron and Aluminium wheels are also available with this series.
| Product Code | S4034B |
|---|---|
| Wheel Diameter (mm) | 100 |
| Frame Type | Swivel with Brake |
| Wheel Width (mm) | 35 |
| Wheel Type | Nylon |
| Wheel Code | NY413 |
| Wheel Bearing Type | Ball Bearing |
| Castor Height (mm) | 130 |
| Swivel Radius (mm) | 125 |
| Maximum Load Capacity (kg) | 200 |
| Recommended Load Capacity (kg) | 150 |
| Download CAD Drawing (STEP file) | Download |
|---|
